Fluke 317 600 Amp True RMS AC/DC Clamp Meter

Description

Shop the Fluke 317 600 Amp True RMS AC/DC Clamp Meter at Peculiar Beauté in South Africa. Use the product specifications below to compare this item with your equipment and project requirements.

Fluke 317 600 Amp True RMS AC/DC Clamp Meter: product details

The listed ac current range (317) is 40.00 A, 600.0 A. The listed ac current accuracy (317) is ±1.6% ±6 digits (40 A, 50-60 Hz)±2.5% ±8 digits (40 A, 60-500 Hz)±1.5% ±5 digits (600 A, 50-60 Hz)±2.5% ±5 digits (600 A, 60-500 Hz). The listed dc current range (317) is 40.00 A, 600.0 A.

Choosing the right item

Compare the stated measurement range, connections and listed test function with the equipment and test requirements. Check the included components and any operating requirements. Match the exact product specification to your task before ordering, since items with similar names can serve different purposes or use different connections.

This item belongs to our electrical test tools range. Review its product code and listed measurements when comparing similar options. Furthermore, check the required accessories before completing your order.

Technical specifications

• AC Current Range (317): 40.00 A, 600.0 A
• AC Current Accuracy (317): ±1.6% ±6 digits (40 A, 50-60 Hz)±2.5% ±8 digits (40 A, 60-500 Hz)±1.5% ±5 digits (600 A, 50-60 Hz)±2.5% ±5 digits (600 A, 60-500 Hz)
• DC Current Range (317): 40.00 A, 600.0 A
• DC Current Accuracy (317): ±1.6% ±6 digits (40 A)±1.5% ±5 digits (600 A)
• AC/DC Voltage Range: 600.0 V
• AC Voltage Accuracy: ±1.5% ±5 digits (20-500 Hz)
• DC Voltage Accuracy: ±1% ±4 digits
• Resistance Range: 400.0 Ω, 4000 Ω
• Resistance Accuracy: ±1% ±5 digits
• Continuity: ≤ 30 Ω
• Frequency (319 only): 5.0 – 500.0 Hz (Accuracy: ±0.5% ±5 digits)
• Inrush Current (319 only): Integration Time: 100 ms
• Crest Factor (Both Models): Add 2% for CF > 2Max CF: 3.0 @ 500 A, 2.5 @ 600 A, 1.4 @ 1000 A (319)
• Display: 6000 count resolution
• Clamp Opening / Jaw Size: 1.45 in (37 mm)
• Power Source: Three AAA IEC LR03 batteries
• Battery Indicator: Low battery signal
• Auto Range: Available in Ohms
• Auto Off: Yes, extends battery life
• Hold Function: Yes, screen data hold
• Dimensions: 162.4 x 58.25 x 30.5 mm (6.39 x 2.29 x 1.20 in)
• Weight: Approx. 384 g (13.5 oz) including batteries
• Safety Ratings: CE CertifiedIEC 61010-1 & IEC 61010-2-032CAT III 600V
• IP Rating: IP40
• Operating Temperature: –10 °C to 50 °C (14 °F to 122 °F)
• Storage Temperature: –40 °C to 60 °C (–40 °F to 140 °F)
• Operating Humidity: Up to 90% RH (non-condensing) @ 30 °C
• Altitude (Operating / Storage): 2000 m / 12,000 m
• Vibration: MIL-PRF-28800F Class 2, 5–500 Hz
• Drop Test: 1 m (3 ft) on all six sides
• EMC: Not specified for fields ≥ 0.1 V/m
• Temperature Coefficient: 0.1 × accuracy per °C outside 18–28 °C

Use and care

Follow the product and equipment instructions for connection, testing and interpretation. Inspect the working components before use and apply the method specified for the exact item. Read the relevant instructions before the first use. In addition, choose protective equipment that suits the task and working environment.

Package information

• Package Weight (kg): 0.750000
• Package Length (cm): 9.65
• Package Width (cm): 26.42
• Package Height (cm): 6.35

Before you order

First, compare the exact product code with the item you need. Check whether the name describes a single component, a pack or a complete kit. Next, review the listed size and connection details. Choose compatible parts for your existing equipment, since matching a brand alone does not confirm a fit. Package measurements describe the packed item rather than its working capacity. Finally, check the inclusion notes for separately sold accessories. Keep these details with your order information so you can identify the same item when replacing or expanding your equipment.

Order the Fluke 317 600 Amp True RMS AC/DC Clamp Meter from Peculiar Beauté. Before checkout, compare the specifications and product photos with your requirements. Keep the product code TTESDM317 available if you need to identify this item again.
