MAC AFRIC 32 MM Geared Head Milling Machine (Round Column)

Description

Shop the MAC AFRIC 32 MM Geared Head Milling Machine (Round Column) at Peculiar Beauté in South Africa. Use the product specifications below to compare this item with your equipment and project requirements.

MAC AFRIC 32 MM Geared Head Milling Machine (Round Column): product details

The listed power output is 0.75 KW (1 HP). The listed max. drilling capacity is 32 mm. The listed max. face mill capacity is 80 mm.

Choosing the right item

Compare the working capacity, spindle configuration and power supply with your machining requirements. Check the stated control method, mounting arrangement and included components. Match the complete model specification to your workshop and planned work before choosing compatible tooling.

This item belongs to our milling and cnc machines range. Review its product code and listed measurements when comparing similar options. Furthermore, check the required accessories before completing your order.

Technical specifications

• Power Output: 0.75 KW (1 HP)
• Max. Drilling Capacity: 32 mm
• Max. Face Mill Capacity: 80 mm
• Max. End Mill Capacity: 28 mm
• Max. Tapping Capacity: M 12
• Max. Spindle Stroke: 130 mm
• Max. Distance from Spindle Axis to Column: 260 mm
• At Perpendicular Direction: ± 90°
• Max. Distance from Spindle Nose to Table: 450 mm
• Spindle Taper: MT 3 or R8
• Working Area of Table: 700 x 240 mm
• Forward and Backward Travel of Table: 175 mm
• Left and Right Travel of Table: 400 mm
• Spindle Speeds (50 Hz): 80, 145, 260, 375, 710, 1250 RPM
• Spindle Speeds (60 Hz): 95, 175, 310, 450, 850, 1500 RPM
• Motor Type: ZAY7032FG
• Height without Stand: 1 020 mm

Use and care

Follow the machine instructions for installation, setup and operation. Secure the workpiece and tooling as directed before machining. Read the relevant instructions before the first use. In addition, choose protective equipment that suits the task and working environment.

Package information

• Package Length (cm): 77.00
• Package Width (cm): 88.00
• Package Height (cm): 115.00
• Package Weight (kg): 320.000000

Before you order

First, compare the exact product code with the item you need. Check whether the name describes a single component, a pack or a complete kit. Next, review the listed size and connection details. Choose compatible parts for your existing equipment, since matching a brand alone does not confirm a fit. Package measurements describe the packed item rather than its working capacity. Finally, check the inclusion notes for separately sold accessories. Keep these details with your order information so you can identify the same item when replacing or expanding your equipment.

Order the MAC AFRIC 32 MM Geared Head Milling Machine (Round Column) from Peculiar Beauté. Before checkout, compare the specifications and product photos with your requirements. Keep the product code EMILGH032 available if you need to identify this item again.
