Brake Drum/Disc Lathe 220–240V/50Hz

Description

Shop the Brake Drum/Disc Lathe 220–240V/50Hz at Peculiar Beauté in South Africa. Use the product specifications below to compare this item with your equipment and project requirements.

Brake Drum/Disc Lathe 220–240V/50Hz: product details

The listed model is ELATHE003. The listed product type is Bench Brake Disc and Drum Lathe. The listed country of manufacture is People's Republic of China.

Choosing the right item

Compare the stated working capacity, spindle configuration and power supply with your machining requirements. Check the included tooling, mounting arrangement and operating features. Match the exact machine specification to your workpiece and workshop before selecting additional accessories.

This item belongs to our lathe machines range. Review its product code and listed measurements when comparing similar options. Furthermore, check the required accessories before completing your order.

Technical specifications

• Model: ELATHE003
• Product Type: Bench Brake Disc and Drum Lathe
• Country of Manufacture: People's Republic of China
• Electrical Designation: 230V / 50 Hz
• Overall Height: 655 mm
• Overall Width (Lathe Alone): 802 mm
• Overall Length (Lathe Alone): 670 mm
• Net Weight (Lathe Alone): 270 kg
• Gross Shipping Weight: 285 kg
• Spindle Centreline to Floor — Rotor Configuration: 500 mm (verification required)
• Spindle Centreline to Floor — Drum Configuration: 640 mm (verification required)
• Required Floor / Bench Load Rating: ≥ 300 kg static, level, vibration-damped
• Motor Rated Power: 1.1 kW
• Motor Supply: 230 V AC, 50 Hz, Single Phase
• Recommended Supply-Circuit Rating: 15 A Minimum
• Insulation / Protection Class: B
• IP Rating: IP54
• Spindle Nose / Arbor Diameter: 40 mm
• Maximum Workpiece Mass on Standard Arbor: 50 kg
• Spindle Speed — Belt Position 1 (Low): 130 rpm
• Spindle Speed — Belt Position 2 (High): 320 rpm
• Carriage Feed Speed — Minimum: 0 mm/rev
• Carriage Feed Speed — Maximum: 0.05 mm/rev
• Cross-Feed Handwheel Graduation: 0.05 mm per division
• Twin-Cutter Micro-Dial Graduation: 0.05 (unit verification required)
• Maximum Rotor (Disc) Diameter: 400 mm
• Maximum Rotor (Disc) Thickness: 38 mm
• Maximum Drum Diameter: 350 mm
• Maximum Drum Depth (Drum Height): 100 mm
• Recommended Rough-Cut Depth — Drums: ≤ 0.5 mm per pass
• Recommended Finish-Cut Depth — Drums: Appears to read ≥ 0.10 mm per pass (verification required)
• Recommended Rough-Cut Depth — Rotors: 0.15–0.25 mm per side
• Recommended Finish-Cut Depth — Rotors: 0.10–0.15 mm per side
• Minimum Cut-Depth Caution: Cuts shallower than 0.10 mm per side reduce insert life, as heat does not transfer efficiently
• Gearbox Lubricant — Preferred Grade: ISO VG 32
• Gearbox Lubricant — Acceptable Alternatives: Appears to read ISO VG 20, ISO VG 30, ISO VG 35 (do not mix grades)
• Gearbox Lubricant — Capacity: Approx. 3.5–3.8 L; sight glass between 1/2 and 2/3 full
• Gearbox Oil-Change Interval: 720 operating hours OR 6 months

Use and care

Follow the machine instructions for installation, setup and operation. Secure tooling and workpieces as directed and disconnect the supply before maintenance. Read the relevant instructions before the first use. In addition, choose protective equipment that suits the task and working environment.

Package information

• Package Weight (kg): 260.000000
• Package Length (cm): 100.0
• Package Width (cm): 65.0
• Package Height (cm): 86.0

Before you order

First, compare the exact product code with the item you need. Check whether the name describes a single component, a pack or a complete kit. Next, review the listed size and connection details. Choose compatible parts for your existing equipment, since matching a brand alone does not confirm a fit. Package measurements describe the packed item rather than its working capacity. Finally, check the inclusion notes for separately sold accessories. Keep these details with your order information so you can identify the same item when replacing or expanding your equipment.

Order the Brake Drum/Disc Lathe 220–240V/50Hz from Peculiar Beauté. Before checkout, compare the specifications and product photos with your requirements. Keep the product code ELATHB003 available if you need to identify this item again.
